Help

capabilities chart
Models
mediaDROID-90
mediaDROID-150
mediaBOX-200
mediaBOX-300


Performance

pick the hardware that’s right for you

Processor

key component for smooth playback

1.6Ghz Quad ARM®
Cortex™-A9
1.7Ghz Quad ARM®
Cortex™-A9
Intel™ core i3
Dual Core
Intel™ i5
Dual Core

Memory

operating memory

2GB DDR3
2GB DDR3
2GB DDR3
4GB DDR3

Operating system

pre-installed OS - PNP

Android 4.2
Android 4.1
Windows 7e
Windows 7e

Total screens

run different content in multi screen

1
1
2
2

Storage / Cache

Offline playback local storage

4GB Flash
8GB Flash
32GB SSD
32GB SSD

Physical size

small form factor

142x95x21mm
180x120x25mm
116x112x39mm
116x112x39mm

Display orientation

support vertical & horizontal modes

Both
choose appropriate device
Both
choose appropriate device
Both
landscape and portrait
Both
Landscape and portrait

Network

Internet connectivity

Ethernet / WIFI
10/100 & 802.11 b, g, n
Ethernet / WIFI
10/100 & 802.11 b, g, n
Ethernet / WIFI
100/1G / 802.11 b, g, n
Ethernet / WIFI
100/1G / 802.11 b, g, n

Screen resolution

via single or multi HDMI

1920x1080
playback set to 720
1280x720
supports single resolution
1920x1080 x 2
always 1080p
1920x1080 x 2
always 1080p

Video quality playback

frame per second capabilities

Normal
360p about 30 fps
HD
1080p about 30fps
HD
1080p about 30fps
Multi HD
1080p about 30fps

Total USB Ports

external and internal

2
supports USB hub
2
supports USB hub
3
supports USB hub
3
supports USB hub

Power input

power requirements

USB powered
included power supply
120-230V
included power supply
120-230V
included power supply
120-230V
included power supply

SignageController

watchdog process / live monitor

Plug and Play

register account and play

Integrated Audio

via HDMI or external Analog

Full featured player

support all campaign components

Web managed

support all campaign components

Full featured player

support all campaign components

Web managed

remote control from SignageStudio

Live TV

connect TV / Satellite / Cable such as Dish or Direct TV




complex vector animation.

heavy processing of vector based animation





Price

$125.00
$195.00
$595.00
$695.00

mediaDROID-90 player - Quad ARM® 1.6Ghz Cortex™ A9 2GB memory

Choose between the Horizontal or Vertical screen mode device



Add Ethernet dongle $19.00
Add Fly Mouse and keyboard $25.00

The mediaDROID-90 is an inexpensive player designed to deliver dynamic animated content, including HD videos. It is powered by the full version of our SignagePlayer app, so you get all the same set of features in a low powered, plug-N-play, stateless, Android based device. The device is about the size of a matchbox which makes it ideal for small space installations. It ships with a special baked Android operating system, that was developed by MediaSignage to deliver a none interrupted continues playback of your campaigns. Simply plug the enclosed HDMI port onto a screen and use the built in WIFI module to connect to your local wireless router (or via an external Ethernet dongle - sold separately). The device can be powered using a screen’s USB port, therefore an external power supply is not required. The mediaDROID-90 can cache up to 4GB of campaign resources on its internal Flash memory, so it can operate even when the connection to the internet is lost with no interruption to your audience.

Choose the mediaDROID-90h to drive any screen in Horizontal / Landscape mode or mediaDROID-90v that will drive any screen in Vertical / Portrait mode; both are compatible with any HDMI screen.

  • - Loaded with our special baked Android 4.2 Jelly Bean OS and a built in Watchdog (i.e.: SignageController)
  • - Choose between Horizontal (Landscape mode) or Vertical (Portrait mode)
  • - Device operates at 720P HD for performance gains
  • - Plug & play - Connect to any HDMI port, Register the pre loaded SignagePlayer app and begin the presentation playback
  • - Powered by a 1.6Ghz Quad core ARM® Cortex™-A9 / Quad core GPU
  • - 4GB Internal Flash to cache the campaign’s content
  • - Size 142 x 95 x 21mm
  • - 2GB DDR3 memory non-ecc non-reg
  • - Powered from a Screen’s USB port. External Power supply 120V-240V is also included incase a screen does not have a free USB port
  • - When Powered from TV USB port, simply turn TV ON or OFF & device will Turn ON/OFF automatically as well.
  • - Presentation will start automatically on Power in 10 seconds or less (Auto turn ON after power loss)
  • - Ethernet 10/100MB Port to connect the internet over your LAN (sold separately)
  • - FlyMouse / FlyKeyboard for easy initial setup (sold separately)

Learn more

This products carries the standard warranty and return  policy





mediaDROID-150 player - Quad ARM® 1.7Ghz Cortex™ A9 2GB memory

Choose between the Horizontal or Vertical screen mode device



Add Fly Mouse and keyboard $25.00

The mediaDROID-150 delivers stunning graphics and HD video content with its powerful ultra compact 1.7GHz quad core processor. The Samsung Exynos4412 CPU is the same processor used in the most powerful Android tablets; and now you can enjoy the latest in high tech processing right on your signage displays. The mediaDROID-150 has 2GB of operating memory. It also has a special Micro MMC 8GB chip for storage capacity to cache campaign’s files, just incase internet connection is disrupted; the MMC chip is about 100x times faster than conventional Micro SIMMs. A smooth aluminum case ensures the device runs cool and the entire unit measures at only 140x110x25mm, a perfect fit behind your Digital Signage display.

So whether you are placing an interactive kiosk or delivering an elaborate static presentation; a properly executed Digital Signage solution helps to engage customers, and solidifies the relationships between brand and consumer. Digital Signage promises to produce a lasting impression that helps strengthen loyalty for new and repeat customers, and the mediaDROID-150 delivers on that promise.

This high end Android based device can deliver smooth 1080P video content and ships pre loaded with the full version of our SignagePlayer Android app, so you get all the same set of features in a low cost, low powered, plug-N-play, stateless computer. The device ships with a special baked Android operating system, that was developed by MediaSignage to deliver a none interrupted continues playback of your campaigns. Simply plug the included HDMI cable onto a screen and use the built in Ethernet module or wifi module to connect to your local area network. The device is powered by an included 120/240V power supply.

Choose the mediaDROID-150h to drive any screen in Horizontal / Landscape mode or mediaDROID-150v that will drive any screen in Vertical / Portrait mode; both are compatible with any HDMI screen.

  • - Loaded with our special baked Android Jelly Bean OS version 4.2 and a built in Watchdog (i.e.: SignageController)
  • - Supports Horizontal screen modes
  • - Plug & play - Connect to any HDMI port, Register the pre loaded SignagePlayer app and begin the presentation playback
  • - Powered by a 1.7Ghz Quad ARM® Cortex™-A9 / Octa core GPU
  • - 8GB Internal Flash to cache the campaign’s content
  • - 2GB DDR3 memory non-ecc non-reg
  • - External Power supply 120V-240V is included
  • - FL/FR*1,HDMI*1,optical*1
  • - Presentation will start automatically on Power in 10 seconds or less (Auto turn ON after power loss)
  • - Ethernet 10/100MB Port to connect the internet over your LAN
  • - Wireless network: with 150M dual antenna NetCard, Compatible 802.11b/g/n
  • - Remote Control included
  • - Bulk discount available when ordering 10+ units, check with Live chat for more info
  • - Enterprise users receive additional discount on this product, check with Live chat for ordering

Learn more

This products carries the standard warranty and return  policy

mediaBOX-200 V2 player Intel™ i3 1.8GHz Dual core 2GB Memory

in stock, normally ships within 1-2 days

MS-200WV2 mediaBOX-200 with W7e $549.00

Add Wireless module (WIFI) $45.00
Add capture card for LIVE TV (external USB) with dongle $85.00

No more compromising between performance, profile, and price. The mediaBOX-200 is a tiny 4 x 4 x 1.5 inch computing device with the power of the 3rd generation Intel Core i3 Desktop processor. Loaded with a special baked Windows 7 embedded OS that’s built by MediaSignage engineers to provide unparalleled reliability. The Win7e includes special enhancements such as blocking OS pop-ups, disable OS updates, removed unneeded services, registry tweaks and more; all to ensure the best performing dedicated Digital Signage Player. The mediaBOX-200 lower power consumption still delivers highly demanding presentations even when powering two high definition 1920x1080 screens.

Designed specifically for Digital Signage and Kiosk applications, the mediaBOX-200 is packed with hardware features such as BIOS vault technology, fast boot technology, Visual BIOS technology and Anti-Theft Technology. With the reliability of an ultra fast mSata SSD drive, you no longer have to rely on a physical spinning disk, thus guaranteeing the longevity of the player. And when it comes to price, the mediaBOX-200 is priced as low as it can go. The price includes the Microsoft Windows 7 license ($125.00 value) and the SSD 32G drive so you are truly getting the most bang for your buck.

  • - Pre-loaded Windows 7 embedded compiled by MediaSignage
  • - Anti theft mounting option
  • - VESA mount to hang on wall or behind screen (included)
  • - 32G mSATA drive with OS loaded (included)
  • - Internal memory DDR3 2GB memory (included)
  • - Power supply and cord for 120-240V (included)
  • - Dual-Core Intel Core i3-3217U (clocked at 1.8 GHz - 3 MB Cache)
  • - Compact size for a very small footprint
  • - Low power consumption
  • - Dual HDMI 1.4a video output
  • - MSATA mini PCIe port and
  • - Three USB 2.0 ports (one on front)
  • - Audio controller Intel HD Audio
  • - Dimensions: 116.6 x 112 x 39 mm ( 4 x 4 x 1.5 inches )

Learn more

This products carries the standard warranty and return  policy

mediaBOX-300 player Intel™ i5 2.8GHz Next Gen Dual core Quad thread 4GB Memory

in stock, normally ships within 1-2 days

MS-300W mediaBOX-300 with W7e $695.00

The mediaBOX-300  is the top of the line Media Player. The mediaBOX-300 delivers true 64bit, quad threading in a 2.8GHz turbo i5 processor. Perfect for high end vector rendering applications this Player was designed to meet your highest graphic needs. The mediaBOX-300 is a powerhouse media player that packs some serious computation power thus delivering the highest quality digital signage and kiosk presentation to your audience.



  • - Small form factor - install behind screen 116 x 112 x 39mm
  • - Pre loaded with Windows 7 embedded custom MediaSignage image with WatchDog
  • - 32GB mSata (SSD) internal hard drive
  • - 3rd generation Intel® Core™ i5-3427U processor (soldered down) with active fan heatsink
  • - Intel® QS77 Express Chipset
  • - Two SO-DIMM slots supporting up to 16 GB of 1333/1600MHz DDR-3 memory
  • - Intel® Gigabit Ethernet Controller (10/100/1000)
  • - Internal Wifi internal module
  • - x2 Mini-DisplayPort 1.1a ports
  • - x1 HDMI port
  • - Intel® High Definition Audio (Intel® HD Audio)2 subsystem in the following configuration:
  • - x3 USB pors (x1 3.0 and x2 2.0)
  • - 19V, 65W power brick 120V/240V
  • - Vesa Mounting bracket
  • - Supports mediaTV Capture device for Live TV( sold separately)
  • - mediaTV Live capture device (sold separately)
  • - 3-year warranty (BOX/BLK)



Learn more

This products carries the standard warranty and return  policy

mediaTV external USB capture device add-on for mediaBOX-200 V2

Includes Composite and S-Video cable

MS-117 mediaTV USB device for mediaBOX 200V2 with dongle $85.00

This mediaTV capture device supports S-Video, composite and TV antenna Audio / Video input. Designed to work specifically with the mediaBOX-200 V2.

Learn more about the mediaTV here
